Mô tả sản phẩm
  • Giá bán:
  • Liên hệ
Mã sản phẩm:
Bảo hành: 36 Tháng
Tình trạng: Còn hàng
Số lượng
Khuyến mãi
Thông số kỹ thuật
  • Sản phẩm    Bo mạch chủ
  • Tên Hãng    Gigabyte
  • Model    H610M H DDR4
  • CPU hỗ trợ    Intel
  • Chipset    H610
  • RAM hỗ trợ    Support for DDR4 3200/3000/2933/2666/2400/2133 MHz memory modules
  • 2 x DDR4 DIMM sockets supporting up to 64 GB (32 GB single DIMM capacity) of system memory
  • Khe cắm mở rộng    1 x PCI Express x16 slot, running at x16
  • 1 x PCI Express x1 slot
  • Ổ cứng hỗ trợ
    • Chipset:
    • 1 x M.2 connector (Socket 3, M key, type 2260/2280 PCIe 3.0 x4/x2 SSD support)
    • 4 x SATA 6Gb/s connectors
    • Cổng kết nối (Internal)
    • 1 x 24-pin ATX main power connector
    • 1 x 8-pin ATX 12V power connector
    • 1 x M.2 Socket 3 connector
    • 4 x SATA 6Gb/s connectors
    • 1 x CPU fan header
    • 2 x system fan headers
    • 1 x RGB LED strip header
    • 1 x front panel header
    • 1 x front panel audio header
    • 1 x USB 3.2 Gen 1 header
    • 2 x USB 2.0/1.1 headers
    • 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only)
    • 1 x serial port header
    • 1 x Clear CMOS jumper
    • Cổng kết nối (Back Panel)
    • 1 x PS/2 keyboard port
    • 1 x PS/2 mouse port
    • 1 x D-Sub port
    • 1 x HDMI 2.0 port
    • 2 x USB 3.2 Gen 1 ports
    • 4 x USB 2.0/1.1 ports
    • 1 x RJ-45 port
    • 3 x audio jacks
  • LAN / Wireless    Intel® GbE LAN chip (1 Gbps/100 Mbps)
  • Kích cỡ    Micro ATX Form Factor; 23.0cm x 21.5cm
Thông số kỹ thuật
  • Sản phẩm    Bo mạch chủ
  • Tên Hãng    Gigabyte
  • Model    H610M H DDR4
  • CPU hỗ trợ    Intel
  • Chipset    H610
  • RAM hỗ trợ    Support for DDR4 3200/3000/2933/2666/2400/2133 MHz memory modules
  • 2 x DDR4 DIMM sockets supporting up to 64 GB (32 GB single DIMM capacity) of system memory
  • Khe cắm mở rộng    1 x PCI Express x16 slot, running at x16
  • 1 x PCI Express x1 slot
  • Ổ cứng hỗ trợ
    • Chipset:
    • 1 x M.2 connector (Socket 3, M key, type 2260/2280 PCIe 3.0 x4/x2 SSD support)
    • 4 x SATA 6Gb/s connectors
    • Cổng kết nối (Internal)
    • 1 x 24-pin ATX main power connector
    • 1 x 8-pin ATX 12V power connector
    • 1 x M.2 Socket 3 connector
    • 4 x SATA 6Gb/s connectors
    • 1 x CPU fan header
    • 2 x system fan headers
    • 1 x RGB LED strip header
    • 1 x front panel header
    • 1 x front panel audio header
    • 1 x USB 3.2 Gen 1 header
    • 2 x USB 2.0/1.1 headers
    • 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only)
    • 1 x serial port header
    • 1 x Clear CMOS jumper
    • Cổng kết nối (Back Panel)
    • 1 x PS/2 keyboard port
    • 1 x PS/2 mouse port
    • 1 x D-Sub port
    • 1 x HDMI 2.0 port
    • 2 x USB 3.2 Gen 1 ports
    • 4 x USB 2.0/1.1 ports
    • 1 x RJ-45 port
    • 3 x audio jacks
  • LAN / Wireless    Intel® GbE LAN chip (1 Gbps/100 Mbps)
  • Kích cỡ    Micro ATX Form Factor; 23.0cm x 21.5cm
